Product Overview • Rear Panel
SB6121 DOCSIS 3.0® Cable Modem • Installation Guide 4
Uncontrolled Document
ICON FLASHING ON
5 Transmitting or receiving data
on Ethernet port Amber: A device, computer, or hub
is connected to the Ethernet
(10Base-T) or Fast Ethernet
(100Base-T) port
Blue*: High-speed Gigabit Ethernet
(1000Base-T) connection from the
SB6121 to your PC
6 Powers on and off the cable modem
Note: The Energy Conservation switch may be an option that is not
provided by your service provider.
*Blue icon operation is not available in all locations. Your service provider may
implement bonded channels for high-speed Internet and Ethernet connections.
Note: To increase the bandwidth available for receiving and transmitting data, your
service provider may also implement bonded channels for RECEIVE and SEND channel
connections. The LINK icon turns blue when a high-speed Gigabit Ethernet (GigE)
connection is made.
Rear Panel
1
2
3
