Specifications
SURFboard SVG2501 Wireless Voice Gateway
GENERAL
Standards DOCSIS 2.0 and PacketCable
1.0 certified; interoperable with
DOCSIS 1.0 and 1.1 and
compatible with Packet
Cable 1.5; SIP; CableHome 1.1
optional
Cable Interface F-Connector, female, 75 Ω
Network Interface Four 10/100 Ethernet
ports
Wireless Interface 802.11b/g Wi-Fi
Dimensions 9.2 in H x 1.5 in W x 6.1 in D
(23.4 cm x 3.81 cm x 15.6 cm)
Regulatory RoHS compliant, FCC, UL
listed (U.S. and Canada),
Industry Canada, ENERGY
STAR qualified, CoC compliant
INPUT POWER
North America 105 to 125 VAC, 60 Hz
Outside North America 100 to 240 VAC, 50 to 60 Hz
ENVIRONMENTAL
Operating Temperature 32 °F to 104 °F (0 °C to 40 °C)
Storage Temperature
Without Battery –22 °F to 158 °F (–30 °C to
70 °C)
With Battery –14 °F to 140 °F (–10 °C to
60 °C)
Store replacement batteries at 25 °C for optimal
storage life
Operating Humidity 5 to 95% R.H.
(non-condensing)
DOWNSTREAM
Modulation 64 or 256 QAM
Maximum Data Rate* 38 Mbps (256 QAM at
5.361 Msym/s)
Bandwidth 6 MHz
Symbol Rates 64 QAM @ 5.069 Msym/s,
256 QAM 5.361 Msym/s
Operating Level Range –15 to +15 dBmV
Frequency Range 88 to 860 MHz
Input Impedance 75 Ω (nominal)
UPSTREAM
Modulation 8***, 16, 32***, 64***,
128*** QAM or QPSK
Maximum Channel Rate 30 Mbps**
Bandwidth 200 kHz, 400 kHz, 800 kHz,
1.6 MHz, 3.2 MHz, 6.4 MHz***
Symbol Rates 160, 320, 640, 1280, 2560, and
5120*** ksym/s
Operating Level Range
A-TDMA 8 to 54 dBmV (32 QAM, 64
QAM)
8 to 55 dBmV (8 QAM, 16
QAM)
8 to 58 dBmV (QPSK)
S-CDMA 8 to 53 dBmV (all modulations)
Output Impedance 75 Ω (nominal)
Frequency Range 5 to 42 MHz (edge to edge)
TELEPHONY
Line Type 2-wire
Hook State Signaling Loop start
Maximum Line Length
(one-way) 500 ft (AWG 26/0.4 mm @ 65
°C)
DTMF Level Sensitivity Range 0 and –20 dBm
Speech Coding 64 kbps PCM, μ-law or A-law
companding; support for G.711,
G.726, G.728, G.729, G.723.1,
iLBC, and BV16/32 codecs
Line Termination Configurable based on market
needs
Loss Plan
Receive (D/A) 4 dB
Transmit (A/D) 2 dB (configurable based
on market needs)
Loss Plan Tolerance ±1 dB; 60/50 Hz loss >20 dB
(one-way; referenced to off-
hook loss at 1,004 Hz)
Ringing Wave Form Quasi-trapezoidal
Ringing Crest Factor 1.2
NETWORK
Gateway DHCP, NAT, VPN tunneling;
static routing and dynamic IP
routing (RIPv1, RIPv2); SPI
firewall with DoS protection
and intrusion prevention; port,
packet, and URL keyword
filtering; full suite of ALGs;
UPnP IGD 1.0
Wireless LAN 802.11b/g Wi-Fi, WDS bridging,
802.11e WMM admission
control, QoS
Power Management 802.11e WMM power save/U-
APSD (Unscheduled-Automatic
Power Save Delivery)
802.11i Security WEP-64/128, WPA-PSK, WPA,
WPA2, TKIP, AES, 802.1x,
802.11i (pre-authentication)
Mobile Pairing User-friendly Wi-Fi–protected
setup (WPS) for secure mobile
pairing with compatible dual-
mode handset
Regulatory Domains To include US, Canada, ETSI,
World
Transmit Power Output
IEEE 802.11b 19 dBm +1/–1.5 dB at all rates
in all channels
IEEE 802.11g 16 dBm +1/–1 dB at 54 Mbps
in all channels
Receiver Sensitivity > –90 dBm at 11 Mbps;
> –74 dBm at 54 Mbps
Product features may vary by model type.
All features, functionality, and other product specifications are
subject to change without notice or obligation.
