Monster Power HTS 5000 User Manual
Page 22

GROUND
IN
OUT
IN
OUT
IN
OUT
CABLE TV
SATELLITE
ANTENNA
PHONE
OUT 1
IN
OUT 2
BREAKER 15A
PRESS TO RESET
1800W MAX TOTAL
2
1
3
4
5
REMOTE
NORMAL
OUTLET PROGRAMMING SWITCHES
UNSWITCHED SWITCHED DELAY NO DELAY
1
2
3
5
4
NO DELAY
DELAY
DC IN
3~30V
REMOTE
AC IN
110V
0.3A
DC OUT
9~12V
300MA
DELAY
TIME
SWITCH
LONG
(20 seconds)
SHORT
(6 seconds)
TRIGGER
OUT
SWITCH
C) DVD: If you have a DVD player, plug its power cord into the corresponding DVD outlet. If you are using a
LaserDisc player, you can also plug it into this outlet. If you have a LaserDisc player and a DVD player, you
can plug either component into any of these four AC outlets designed for digital components.
D) SPARE: Plug your additional digital component into the corresponding SPARE outlet
E) CD: Plug your CD player’s power cord into the corresponding CD outlet.
