PAGE 30 — DCA-125USJ (50 HZ) — OPERATION AND PARTS MANUAL — REV. #0 (03/11/05)
Voltage Selector Switch
The
voltage selector switch (Figure 16) is located above
the output terminal panel’s
Hard Wire Hook-up Panel. It
has been provided for ease of voltage selection.
CAUTION:
CAUTION:
CAUTION:
CAUTION:
CAUTION:
NEVER change the position of the
voltage
selector switch while the engine is running.
ALWAYS place circuit breaker in the open
position before selecting voltage.
Voltage Selector Switch Locking Button
The voltage selector switch has a locking button to protect
the generator and load from being switched while the engine
is running. To lock the voltage selector switch,
press and
hold the red button located at the bottom of the switch.
Figure 16. Voltage Selector Switch
DCA-125USJ (50 HZ)— GENERATOR OUTPUTS
Generator Amperage
Table 7 describes the generator’s current output capability
for both 1Ø-phase and 3Ø phase applications.
Generator Output Voltages
A wide range of voltages are available to supply voltage for
many different applications. Voltages are selected by using
the
voltage selector switch (Figure 15). To obtain some of
the voltages as listed in Table 6 (see below) will require a
fine adjustment using the
voltage regulator (VR) control
knob located on the control panel.
