DCA-400SPK — PARTS AND OPERATION MANUAL — REV. #0 (06/19/01) — PAGE 97
ENCLOSURE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
DCA-400SPK — ENCLOSURE ASSY.
ADD THE FOLLOWING DIGITS AFTER THE PART NUMBER
WHEN ORDERING ANY PAINTED PANEL TO INDICATE
COLOR OF UNIT:
1-ORANGE
2-WHITE
3 -SPECTRUM GRAY
4 -SUNBELT GREEN
5 -BLACK
6 -CATERPILLAR YELLOW
7 -CATO GOLD
8 -RED
THE SERIAL NUMBER MAY BE REQUIRED.
60 8195151004 LOUVER PANEL 2
61 8215151004 LOUVER PANEL 1
62 0207006000 HEX. NUT 18
63 8215176004 DUCT 2
8215974504 LINING 1
64 8215176204 DUCT 1
8215103404 LINING 1
65 0017108020 HEX. HEAD BOLT 18
66 0825007362 DOOR HANDLE 7
0605010225 KEY 1
67 0021806016 MACHINE SCREW 28
68 0845046904 HINGE 8
0845045004 WASHER 8
69 0845047004 HINGE 8
0845045004 WASHER 8
70 0019208020 HEX. HEAD BOLT 40
71 0601850097 STOPPER 10 .......... 30029
72 0021008025 MACHINE SCREW 10
73 0845031504 CAP 20
74 8215312002 SUPPORT LEG 1
75 0017110030 HEX. HEAD BOLT 3
76 0010110030 HEX. HEAD BOLT 2
0030010000 HEX. NUT 2
0040010000 LOCK WASHER 2
0041210000 PLAIN WASHER 2
77 6360510003 EMBLEM 2
78 0021106020 MACHINE SCREW 4
