DCA-400SPK — PARTS AND OPERATION MANUAL — REV. #0 (06/19/01) — PAGE 91
ENCLOSURE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 8215111022 BASE 1
2 3515116114 FLOOR PANEL 1
3 8215116004 FLOOR PANEL 1
4 0019208020 HEX. HEAD BOLT 14
5 8215020204 FRONT FRAME 1
8215102003 LINING 1
6 0019110025 HEX. HEAD BOLT 8
0042310000 LOCK WASHER 8
0042410000 PLAIN WASHER 8
7 8225125104 COVER, FRONT FRAME 1
8 8225125204 COVER, FRONT FRAME 1
8225102104 LINING 1
9 0019208020 HEX. HEAD BOLT 28
10 0845042703 FILLER BRACKET 1
11 0019208020 HEX. HEAD BOLT 4
12 8215125003 COVER, FRONT FRAME 1
13 0019208020
14 8215131202 CENTER FRAME 1
15 0010120070 HEX. HEAD BOLT 6
0030020000 HEX. NUT 6
0040020000 LOCK WASHER 6
0041220000 PLAIN WASHER 12
16 0010120060 HEX. HEAD BOLT 8
0030020000 HEX. NUT 8
0040020000 LOCK WASHER 8
0041220000 PLAIN WASHER 16
17 8215041414 REAR FRAME 1
8215940304 LINING 1
18 8225151004 LOUVER PANEL 1
19 0207006000 HEX. NUT 18
DCA-400SPK — ENCLOSURE ASSY.
ADD THE FOLLOWING DIGITS AFTER THE PART NUMBER
WHEN ORDERING ANY PAINTED PANEL TO INDICATE
COLOR OF UNIT:
1-ORANGE
2-WHITE
3 -SPECTRUM GRAY
4 -SUNBELT GREEN
5 -BLACK
6 -CATERPILLAR YELLOW
7 -CATO GOLD
8 -RED
THE SERIAL NUMBER MAY BE REQUIRED.
