MTD 500 thru 510 User Manual
Page 17
17
Model Series 500 thru 510
Ref.
No.
Part No.
Part Description
1.
718-0773
Hydraulic Cylinder
2.
727-0634
Hydraulic Tube
3.
710-1018
Hex Cap Screw 1/2-20 x 2.75
4.
737-0192
90 Degree Solid Adapter
5.
718-0481
Control Valve
6.
737-0153
Return Elbow
7.
737-0238
Nipple Pipe 1/2-14
8.
710-0515
Hex Cap Screw 1/2-20 x 3.50
9.
719-0550
Wedge Assembly
10.
712-0239
Lock Nut 1/2-20
11.
712-0711
Hex Jam Nut 3/8-24
12.
710-0459A
Hex Cap Screw 3/8-24 x 1.5
13.
781-0351
Adjustable Gib
14.
710-0604A
Hex Washer Screw 5/16-18 x .625
15.
781-1054
Support Bracket
16.
681-0173
Beam Assembly
17.
736-0300
Flat Washer .406 ID x .875 OD
18.
710-0654A
Hex Washer Screw 3/8-16 x 1.0
19.
781-0791
Dislodger
20.
781-0790
Back Plate
21.
736-0921
Lock Washer 1/2
22.
727-0443
Return Hose 3/4” ID x 44” Lg.
23.
726-0132
Hose Clamp 5/8”
24.
737-0316
Filter Housing
25.
723-0405
Oil Filter
26.
734-0873
Hub Cap
27.
714-0162
Cotter Pin
28.
712-0359
Slotted Nut 3/4-16
29.
634-0186
Wheel Assembly
30.
736-0351
Flat Washer .760 ID x .500 OD
31.
737-0312
Adapter 3/4-14
32.
710-1338
Hex Screw 5/16-24 x 3.25
33.
737-0348
Vented Dipstick
34.
711-1587
Clevis Pin
35.
781-0690
Lock Rod
36.
714-0470
Cotter Pin
37.
726-0214
Push Cap
38.
732-0583
Compression Spring
39.
781-0686
Log Tray Bracket
40.
710-3097
Carriage Bolt 3/8-16 x 1.0
41.
712-0431
Flanged Lock Nut 3/8-16
42.
781-0682
Log Tray
43.
681-0161
Frame Assembly
44.
710-0521
Hex Bolt 3/8-16 x 3”
45.
719-0353
Coupling Shield
46.
714-0122
Square Key 3/16” x .75
47.
718-0686
Flexible Coupling
48.
712-0123
Hex Nut 5/16-24 †
49.
781-0097
Rear Coupling Support Bracket
50.
736-0119
Lock Washer 5/16” ID
51.
727-0633
Hose
52.
718-0683
Gear Pump (11gpm)
53.
737-0329
45 Degree Elbow
54.
727-0502
High Pressure Hydraulic Hose
55.
781-0788
Tube Assembly
56.
747-1261
Latch Rod
57.
781-1045
Latch
58.
732-3127
Spring Compression
59.
736-0169
L-Washer 3/8”
60.
712-0798
Hex Nut 3/8-16
61.
710-0944
Hex Cap Screw 3/8-16 x 4.25
62.
736-0262
Flat Washer .385 ID x .870 OD
63.
750-0497
Spacer .375 ID x .625 OD
64.
727-0311
Coupling Hitch
65.
713-0433
Chain
66.
712-0375
Hex Lock Nut 3/8-16
67.
711-0813
Clevis Pin
68.
736-0185
Flat Washer .375 ID x .738 OD
69.
732-0194
Spring Pin
70.
781-0789
Jack Stand
71.
715-0120
Spiral Pin
Ref.
No.
Part No.
Part Description
