GENERAL VHF UHF
Channel Capacity 4
Typical RF Output 1-25W 1-25W
Frequency 136-174MHz 403-470 MHz
450-527 MHz
Dimensions (H x W x L) 56 mm x 176 mm x 177 mm (2.2" x 6.93" x 6.97")
Weight 1.43 kg. (3.15 lbs)
Current Drain:
Standby
.3 A .3 A
Rx @ rated, external 8 ohm speaker 1.5 A 1.5 A
Transmit 7A @ 25W 8 A @ 25W
TRANSMITTER VHF UHF
Frequencies 136-174 MHz 403-470 MHz / 450-527MHz
Channel Spacing 12.5/20/25 kHz
Frequency Stability (-30° C to +60° C, +25° Ref.) ± 2.5 ppm
Power Output 1-25W 1-25W
Modulation Limiting ±2.5 @12.5 kH / ±4.0 @ 20kHz / ±5.0 @25 kHz
FM Hum & Noise -40 dB 12.5 kHz / -45 dB 25 kHz
Conducted/Radiated Emission -36 dBm < 1 GHz / -30 dBm > 1 GHz
Adjacent Channel Power -60 dB @ 12.5 kHz / -70 dB @ 25 kHz
Audio Response TIA 603 & ETS300 & ETS 300 / CEPT 84
CEPT 84 Annex 2 Annex 2
Audio Distortion 3% typical
RECEIVER VHF UHF
Frequencies 136-174 MHz 403-470 MHz
450-527 MHz
Channel Spacing 12.5/20/25 kHz
Frequency Stability (-30° C to +60° C, +25° Ref.) ± 2.5 ppm
Sensitivity (12 dB SINAD) 0.3 µV
0.23 µV typical
Intermodulation 75 dB @ 12.5 kHz 75 dB @ 12.5 kHz
78 dB @ 25 kHz 75 dB @ 25 kHz
Adjacent Channel Selectivity 65 dB @ 12.5 kHz 65 dB @ 12.5 kHz
80 dB @ 25 kHz 75 dB @ 25 kHz
Spurious Rejection 75 dB @ 12.5 kHz VHF 70 dB @ 12.5 kHz
80 dB @ 25 kHz VHF 75 dB @ 25 kHz
Rated Audio (external audio with 4 ohm speaker) 3W Internal / 7.5W & 13W External
Audio Distortion @ Rated Audio 3% typical
Hum and Noise -40 dB 12.5 kHz / -45 dB 25 kHz
Audio Response TIA603 & ETS300 & CEPT 84 Annex 2
Conducted Spurious Emission -57dBm < 1 GHz / -47 dBm > 1 GHz
BTB MA116
Availability subject to country's law and regulation.
Radios meet applicable regulatory requirements.
All specifications shown are subject to change without notice.
Specifications are not representative of all radios and may vary in different radios.
Visit us at www.motorola.com/cgiss/AP
MOTOROLA, THE Stylized M Logo are registered in the
U.S. Pat. & Tm. Office. All rights reserved. All other product
or service names are the property of their respective
owners.
© 2003 Motorola, Inc.
GM328.01AUST 10/03
One-Year Warranty
Each Motorola radio is backed by a one-year
warranty on radio parts and labour.
Accelerated Life Testing
Motorola’s Accelerated Life Testing simulates
five years of hard use in real life, EIA RS-316B
in Shock, Vibration, Dust, Humidity, IP54 for
Sealing.
MIL-STD 810C, D and E
Stamp of approval from the U.S. Military for
use in rough environments.
ISO 9001 Standard
Compliance with ISO 9001 Standard - an
international quality system assurance on
design, development, production, installation
and servicing of a product.
For more information, please contact:
Portable Military Standards 810 C
Applicable MIL-STD Methods Procedures
Low Pressure 500.1 1
High Temperature 501.1 1,2
Low Temperature 502.1 2
Temperature Shock 503.1 1
Solar Radiation 505.1 1
Rain 506.1 2
Humidity 507.1 2
Salt Fog 509.1 1
Dust 510.1 1
Vibration 514.2 8,10
Shock 516.2 1,5
Portable Military Standards 810 D
Applicable MIL-STD Methods Procedures
Low Pressure 500.2 2
High Temperature 501.2 1,2
Low Temperature 502.2 1,2
Temperature Shock 503.2 1
Solar Radiation 505.2 1
Rain 506.2 2
Humidity 507.2 2,3
Salt Fog 509.2 1
Dust 510.2 1
Vibration 514.3 1
Shock 516.3 1
Portable Military Standards 810 E
Applicable MIL-STD Methods Procedures
Low Pressure 500.3 2
High Temperature 501.3 1,2
Low Temperature 502.3 1,2
Temperature Shock 503.3 1
Solar Radiation 505.3 1
Rain 506.3 2
Humidity 507.3 3
Salt Fog 509.3 1
Dust 510.3 1
Vibration 514.4 1
Shock 516.4 1
