D ESIGN S PECIFICATIONS
MS1690 D ESIGN S PECIFICATIONS
O PERATIONAL
Light Source: LED 645 nm
Pulse Duration: 1 ms to 8 ms
Maximum Output
of an Osram LED:
Maximum 85 mA emits 3,120 mlm
Depth of Scan Field:
0 mm – 230 mm (0" – 9") for
0.330 mm (13 mil) Bar Code at Default Setting
49 mm W x 19 mm H (1.9” W x 0.8” H) at 20 mm (0.8”)
Field of View:
264 mm x 106 mm (10.4” W x 4.2” H) at 280 mm (11.0”)
Minimum Bar Width: 0.127 mm (5.0 mil)
Long Range: 0 mm – 203 mm (0" – 8") from Window
Infrared Activation:
Short Range: 0 mm – 101 mm (0" – 4") from Window
Decode Capability:
Autodiscriminates All Standard 1-D, RSS, PDF417,
microPDF, MaxiCode, Data Matrix, QR Code, UCC, EAN
Composites, Postals, Aztec
(Image Transfer) – BMP, TIFF, or JPEG output
System Interfaces:
PC Keyboard Wedge, RS232, IBM 468X/469X, Stand
Alone Keyboard, USB (Low Speed and Full Speed)
Print Contrast: 20% Minimum Reflectance Difference
Number Characters Read:
Up to 80 Data Characters on 1D;
1850 Text Characters for PDF417
Beeper Operation: 7 tones or no beep
Blue Unit Powered, Ready to Scan
White Good Read
Indicators (LED)
Default Settings:
Yellow In Stand
M ECHANICAL
Height: 183 mm (7.2")
Handle - 30 mm (1.2")
Width:
Head - 79 mm (3.1")
Depth: 111 mm (4.9")
Weight: 225 g (8.0 oz)
Termination: 10 pin modular RJ45
Cable: Standard 2.7 m (9') Coiled; Optional 2.1 m (7’) Straight
Specifications are subject to change without notice.
