25
At a glance
Instrument cluster
Item Page
1 L Left turn signal indi-
cator lamp
51
2 v ESP warning lamp 358
3 Speedometer
4 Multifunction display
137
5 l Distance warning
lamp
Warning lamp without func-
tion. It illuminates with the
ignition on. It should go out
when the engine is running.
6 K Right turn signal indi-
cator lamp
51
7 Coolant temperature indi-
cator with:
135
•
Coolant temperature
warning lamp 357,
376
Item Page
8 Tachometer with: 136
1 Supplemental
restraint system
indicator lamp
359,
386
- Antilock Brake Sys-
tem (ABS) warning
lamp
354
< Seat belt telltale 359,
386
A High beam headlamp
indicator lamp
129
B Low beam headlamp
indicator lamp
129
9 Main odometer with:
ț Gear selector lever posi-
tion 166
ț Program mode 170
Item Page
a Clock with: 151
; Brake warning lamp,
USA only
355
3 Brake warning lamp,
Canada only
? Engine malfunction
indicator lamp,
USA only
356
± Engine malfunction
indicator lamp,
Canada only
356
b Fuel display with:
A Fuel reserve warning
lamp
359
c Reset button for:
ț Resetting trip odometer 135
ț Adjusting instrument
cluster illumination 134
ț Confirming new time set-
tings 151
