SYSTEM EXPANSION
3/5
I/O ports Default assignment
All addresses below 100h are used by the system board for various
fixed system components and chipset controller settings.
They are unavailable for use.
1F0h-1F7h Hard disk drive controller
200h-207h Game I/O
278h-27Fh Parallel port 2
2B0h-2DFh Alternate VGA
2F8h-2FFh Serial port 2
378h-37Fh Parallel port 1
3B0h-3BFh Monochrome display and printer adapter
3B4h, 3B5h, 3BAh Video subsystem
3C0h-3C5h VGA
3C6h-3C9h Video DAC
3CAh-3DFh VGA
3F0h-3F7h Diskette drive controller
3F8h-3FFh Serial port 1
Base memory address
Some expansion cards are fitted with memory of their own, usually
read-only memory (ROM) containing functional extensions to the
computer’s BIOS (basic input/output system) ROM. Some cards also
have random-access memory (RAM).
In order that this memory can be recognised by the system
processor, it must be mapped somewhere within the computer’s own
address space. By setting the base memory address you specify
where the card’s memory begins within the address space. Typically,
an expansion card’s memory must be mapped onto the addresses
between C8000h and EFFFFh in upper memory. With most modern
expansion cards this is fully automatic.
