Dimâge Scan Dual II 59
FOCUS – MANUAL
Use manual focus on a specific area of the image or to reduce the appearance of grain in
grainy film (such as high-speed or pushed film) by slightly defocusing it.
MANUAL FOCUS
1. Click on .
• The pointer will change to the Manual Focus icon.
• Click on the Manual Focus button again to escape the
function.
2. Click on the area of the image to be in sharp
focus.
• The Focus Control Window dialog box will appear.
3. Adjust the slider until the black and gray lines are
at their longest for maximum focus.
• Click and drag the slider to the left and right.
Click on the slider bar to make a larger
change.
• To slightly defocus, adjust the sliders until the
black bar is a little shorter than the gray bar.
4. Click on .
• A new prescan will begin.
• The prescanned image will appear in the
Prescan tab when complete.
