NiMH Battery

Your Spirit GT radio operates on a
N ick el M et al Hy dr ide (N iM H)
rechargeable battery. The NiMH
rechargeable battery will provide up
to 9 hours of operation with normal
use. Standard 5/5/90 duty cycle
(5% transmit, 5% receive, 90%
standby).

Removing the Battery Door:

1. Grasp radio with one hand,

display side down (do not hold
radio antenna).

2. Slide battery door back half-way

until you feel resistance.
Figure 3.

3. Remove battery door from radio

by lifting door up as shown.
Figure 4.

Figure 2.

Figure 3.

Figure 4.

Step 1

Step 2

Step 3
