E33
PARTS LIST
ENGINE PARTS - MODELS YM26CO, YM26CS & YM26SS
4-CYCLE GAS TRIMMER
Item Part No. Description
1 753-1222 Engine Cover
2 791-182339 Engine Cover Screws
3 791-181025 Valve Cover Screw
4 791-182098 Valve Cover
5 791-182099 Valve Cover Gasket
6 791-182340 Rocker Adjustment Nut
7 791-182101 Rocker Arm Pivot
8 791-182100 Rocker Arm
9 791-182341 Rocker Arm Stud
10 791-182103 Valve Spring Retainer
11 791-181038 Valve Spring
12 791-182102 Push Rod Guide
13 791-181033 Push Rod
14 791-182745 Cylinder Head (includes 9-12)
15 791-182344 Cylinder Screw
16 753-1226 Intake Baffle
17 791-182749 Carburetor Mount Gasket
18 791-181034 Nut
19 791-182347 Carburetor Mount
20 791-182348 Carburetor Mount Screw (includes 18)
21 791-182732 Carburetor Gasket
22 753-1225 Carburetor with Primer
23 791-181751 O-Ring, Carburetor
24 791-182350 Air Filter Assembly (includes 27 & 28)
25 791-182097 Breather Tube
26 791-181750 Air Filter Mounting Screw
27 791-181757 Air Filter
28 791-182351 Air Filter Cover
29 791-182271 Fuel Cap
30 791-182352 Fuel Return Line
31 791-182353 Fuel Pick-Up Line with Filter
32 753-04510 Screw
33 791-182355 Fuel Tank Assembly
34 791-182356 Fuel Tank Shield
35 753-1231 Throttle Cable
36 753-1232 Muffler Baffle
37 791-181048 Muffler Gasket
38 791-182359 Muffler (includes 37 & 39-41)
39 791-180890 Spark Arrestor Screen
40 791-181045 Screen Cover
41 791-181046 Screw
42 791-182361 Muffler Mounting Screw
43 753-04092 Muffler Cover
44 791-182365 Switch with Wires
Item Part No. Description
45 791-181247 Pulley Retainer
46 753-1199 Recoil Pulley
47 753-04286 Recoil Spring
48 791-182366 Nut Clip
49 791-181079 Pull Handle
50 791-611061 Rope Guide
51 791-613103 Rope
52 791-181020 Starter Housing Screw
53 753-04127 Starter Housing Assembly (includes 45-52)
54 791-182368 Clutch Washer
55 753-1238 Clutch with Spacer
56 791-153592 Clutch Drum
57 753-1239 Clutch Cover
58 791-145569 Anti-Rotation Screw
59 753-1240 Screw
60 791-181345 Clutch Cover Screw
61 791-182725 Ignition Module with Screws
62 791-181065 Spacer
63 791-182736 Flywheel
64 791-182743 Shroud Assembly w\Screws
65 791-182376 Crankcase Assembly (includes 66 & 67)
66 791-182375 90° Elbow
67 791-182379 Breather Hose
68 791-181015 Cam Gear
69 753-1242 Cam Follower
70 791-181013 Cam Bracket
71 791-181012 Cam Bracket Screw
72 791-181040 Valves, Intake and Exhaust
73 791-182374 Cylinder Gasket
74 791-181018 Oil Pan Gasket
75 791-182377 Oil Pan (includes 74 & 76)
76 791-181020 Oil Pan Screw
77 791-182378 Dipstick Assembly (includes 78)
78 791-182290 O-Ring
79 791-181009 Connecting Rod
80 791-181008 Wrist Pin Button
81 753-1243 Piston
82 791-181006 Wrist Pin
83 753-04801 Piston Ring Set
84 791-182409 Washer
85 791-181861 Screw
86 753-1241 Nut
* 791-180852B Spark Plug
* 753-04087 Short Block Assembly (includes 3-15, 65-84)
* 791-180142 Starter Pawl Repair Kit
* Parts not shown
