7
ENGLISH
II. BASE PAD KIT - see Figure 2-2
NOTE: One Base Pad Kit is required for each Single, Double, Triple, or Quad Oven installation.
Qty.
Single Double Double Triple Quad
oven oven with oven with oven oven
Item 10" legs 15" legs Part No. Description
1a 4 -- -- -- -- 37210-0060 Leg extension, 19" (483mm)
1b -- 4 -- -- -- 37210-0082 Leg extension, 10" (254mm)
1c -- -- 4 -- -- 37210-0057 Leg extension, 15" (381mm)
2 4 4 4 4 -- 37115-0102 Caster, swivel, with 3/4" mounting stud
3 -- -- -- -- 2 22290-0010 Caster, swivel, with flat mounting plate
4 -- -- -- -- 2 22290-0009 Caster, swivel, with flat mounting plate and brake
5 1 1 1 1 1 22361-0003 Flexible gas hose, 1-1/4” dia. X 72” (1829mm) L
6 2 2 2 2 2 27271-0004 Pipe clamp, 1-1/2”
7 2 2 2 2 2 33120-0055 Nipple, 1-1/4” dia. X 3” (76mm) L, NPT
8 2 2 2 2 2 23122-0007 Elbow, 90°, 1-1/4” dia.
9 4 4 4 4 -- 22450-0028 Adjustable leg, 6" (152mm)
10 1 1 1 1 1 33120-0056 Gas pipe, 1-1/4” dia. X 54” (1372mm) L
11 1 1 1 1 1 22450-0253 Restraint cable, 60” (1524mm) L
12 1 1 1 1 1 21392-0005 Eyebolt
13 1 1 1 1 1 37210-0055 Base pad
-- 2 2 2 2 2 35210-0656 Top cover (Right or Left)
-- 8 8 8 8 8 21256-0069 Screw, slt trs hd, #10-32 X 1-1/4”
-- 2 2 2 2 2 21292-0001 Screw, hex washer hd, #10-16 X 3/4”
-- 16 16 16 -- 8 21216-0018 Bolt, hex cap, 1/2"-13 X 1-1/4”
-- 16 16 16 -- 8 21416-0003 Flat washer, 1/2”
-- 16 16 16 -- 8 21426-0004 Lock washer, 1/2”
-- -- -- -- -- 16 21216-0001 Bolt, hex cap, 3/8"-16 X 1”
I. INSTALLATION KIT - see Figure 2-1
NOTE: One Installation Kit is required for each oven cavity.
Item Qty. Part No. Description
1 1 35900-0148 Conveyor rear stop
2 1 35000-1103 Conveyor end stop
3 1 33120-0053 Gas pipe nipple
4 1 39141 Owner's Operating and Installation Manual, PS570S Gas Ovens
5 1 1002040 Middleby Marshall Authorized Service Agency Listing
SECTION 2 - INSTALLATION
