SECTION 4
MAINTENANCE
D. Reinstall End Plugs
1. Reinstall lower end plug (has flange that extends into
oven). Place and secure plastic wing nuts on the end plug.
2. Reinstall conveyor.
3. Reinstall upper end plug (no inner flange). Place and
secure plastic wing nuts on the end plug.
2EMOVABLE
#ONVEYOR
!SSEMBLY
#ASTERS
4EMPERATURE
#ONTROLLER
3PEED
(EAT#ONVEYOR
3WITCH
-AIN"LOWER
3WITCH
2EMOVABLE
%ND
2EMOVABLE
%ND
Figure 4-17.
Figure 4-18.
