I. CONTROL FUNCTIONS
WARNING
A possibility of injury from rotating parts and
electric shock exists in this oven.
Never disassemble or clean the oven with the
BLOWER switch or any other oven control turned
“ON” or “I”. Turn “OFF” or “O” and lockout or
tagout all electric power to the oven before
attempting to clean or service this oven.
Figure 3-1. PS624-Series Oven Control Functions
4EMPERATURE
#ONTROLLER
3PEED
(EAT#ONVEYOR
3WITCH
-AIN"LOWER
3WITCH
