M S-7304 M ainboard
3-14
information stored in memory will be used to restore the sys-
tem when a
“wake up” event occurs.
Re-Call VGA BIOS from S3
Selecting [Enabled] allows BIOS to call VGA BIOS to initialize the VGA card when
system wakes up (resumes) from S3 sleep state. The system resume time is short-
ened when you disable the function, but system will need an AGP driver to initialize
the VGA card. Therefore, if the AGP driver of the card does not support the initializa-
tion feature, the display may work abnormally or not function after resuming from S3.
Suspend Time Out (M inute)
If system activity is not detected for the length of time specified in this field, all
devices except CPU will be shut off.
Soft Off by PWR BTTN
W hen [Enabled], turning the system off with the on/off button places the system in a
very low-power-usage state, with only enough circuitry receiving power to detect
power button activity or Resume by Ring activity.
Restore on AC Power Loss
This item specifies whether your system will reboot after a power failure or interrupt
occurs.
[Off] Always leaves the computer in the power off state.
[On] Always leaves the computer in the power on state.
[Previous State] Restores the system to the status before power failure
or interrupt occurred.
Wakeup Event Setup
Resume From S3 By USB Device
The item allows the activity of the USB device to wake up the system from S3
(Suspend to RAM) sleep state.
Resume By PCI Device (PM E#)
W hen set to [Enabled], the feature allows your system to be awakened from the
power saving modes through any event on PME (Power Management Event).
Resume By PCI-E Device
W hen set to [Enabled], the feature allows your system to be awakened from the
power saving modes through any event on PCIE device.
Resume By RTC Alarm
The field is used to enable or disable the feature of booting up the system on a
scheduled time/date.
