2 MAINTENANCE
CHARTS
2-8
TIMER SETTINGS
RAM STOP REAR
RAM STOP FORWARD
MODEL NO.
T1
T2
T1
T2
RJ-88SC
27
17
17
27
RJ-100SC
21
16
16
21
RJ-250SC
19
13
13
19
RJ-250VL
21
16
16
21
Includes HT units and SL units.
FUSES AND CIRCUIT BREAKERS
MOTOR
FULL
DUAL ELEMENT CIRCUIT
SERVICE
SIZE
VAC
LOAD
FUSE
BREAKER DISCONNECT
AMP.
MAX. SIZE
MAX. SIZE
AMP.
5 HP, 1 PH
208
22.0
50
80
60
230
20.8
45
70
60
5 HP, 3 PH
208
13.8
30
40
30
230
13.4
25
40
30
460
6.7
15
20
30
575
5.4
10
15
30
10 HP, 1 PH
208
43.0
100
125
100
230
39.0
90
125
100
10 HP, 3 PH
208
27.5
50
80
60
230
26.4
50
70
60
460
13.2
25
35
30
575
11.4
20
30
30
