7
Functional Overview
Front and Rear Panels
Mains Cord
– connect to power outlet
AUDIO OUT (Left/Right)
– connect to AUDIO inputs of an
amplifier, receiver or stereo system
Video out (CVBS)
– connect to a TV with CVBS inputs
Coaxial output
– connect to a receiver with coaxial inputs
Caution: Do not touch the inner pins of the sockets on the rear panel. Electrostatic
discharge may cause permanent damage to the unit.
TV OUT (VIDEO OUT)
– connect to a TV with SCART
OPEN/CLOSE OPEN/CLOSE
MIC
LEVEL
STOP STOP PLAY/ PLAY/PAUSE PAUSE
IR
DVD VIDEO / CD PLAYER MDV423
STANDBY TANDBY-ON ON
STANDBY-ON
– switches DVD ON or to standby mode
Disc Tray
DISPLAY
– shows the current status of the player
/ OPEN/CLOSE
– opens/closes the disc tray
B PLAY/PAUSE
– star ts/interrupts playback
9 STOP
– stops playback
