2 Model JR3020
1
256654-3
1
Pin 4
2
266242-8
1
Hex Socket Bolt M5x45 (Old 922907-9)
3
942101-7
1
Spring Washer 5
4
344095-6
1
Shoe Plate
5
961017-7
1
Stop Ring E-3
6
252103-8
1
Hex Lock Nut M5-8
7
344096-4
1
Shoe Supporter
8
265836-6
1
Screw M8x9
9
*
1
Leaf Spring
10
*
1
Blade Clamp
11
*
1
Hex Socket Head Bolt
12
421451-8
1
Insulation Cover
13
159614-3
1
Gear Housing Cover Com.
(Includes Items 92 & 93)
14
961012-7
1
Stop Ring E-6
15
961012-7
1
Stop Ring E-6
16
*
1
Dust Seal
17
*
1
Slider Support
18
231342-3
2
Compression Spring 4
19
*
1
Linear Ball Bearing/Plane Bearing
20
*
1
Slider
21
214161-2
1
Plane Bearing 12.7
*
22
*
2
Screw M5x16
23
343980-0
1
Plate (B)
24
343983-4
1
Arm
25
265011-4
2
(+) Binding Head Screw M5
26
343981-8
1
Plate (C)
27
251969-3
2
Hex Socket Head Bolt M5x12
28
*
2
Screw M5x16
29
*
1
Plate
30
212308-2
1
Thrust Needle Bearing 2035
31
153218-3
1
Gear (Includes Pin 7 - #256197-5)
32
211519-6
1
Ball Bearing 6808
33
253816-4
1
Falt Washer 6
34
251969-3
1
Hex Socket Head Bolt M5x12
35
*
1
Pin 7
36
272228-2
1
Lever 20
37
231309-1
1
Compression Spring 5
38
415173-0
1
Stopper
39
257106-7
1
Ring 8
40
343982-6
1
Lever Plate
41
921432-7
1
Hex. Bolt M8x20
42
272227-4
1
Lever 50 (Type 1)
272235-5
1
Lever 50 (Type 2)
43
912202-5
1
Countersunk Head Screw M5x8
(Type 1)
922201-9
1
Countersunk Head Screw M5X8
(Type 2)
44
212038-5
1
Needle Bearing 710
45
911601-8
2
P.H. Screw M5x8
46
212115-3
1
Needle Bearing 1216
47
321263-8
1
Gear Shaft
48
316464-1
1
Gear Housing
49
911243-8
4
P.H. Screw M5x25
50
911621-2
1
P.H. Screw M5x16
51
911213-7
3
P.H. Screw M5x12
52
961052-5
1
Retaining Ring S-12
53
211131-2
1
Ball Bearing 6001DDW
54
285675-8
1
Bearing Retainer
55
241863-7
1
Fan 70
56
516166-1
1
Armature Assy(MJ)(Includes Items 55, 57 & 58)
616241-4
1
Armature (MCA) (Includes Items 55 & 57)
57
681625-5
1
Insulation Washer
58
210005-4
1
Ball Bearing 608DDW
59
415174-8
1
Speed Control Knob
60
*
1
Handle (R)
61
*
1
Motor Housing Com. (Includes
2 Brush Holders - #643751-8
& Rubber Pin 4 - #263002-9)
62
191941-2
2
Carbon Brush CB-251 (Old 191937-3 CB-250)
63
643750-0
2
Brush Holder Cap (MJ)
643755-0
2
Brush Holder (MCA)
64
410048-8
1
Wrench Holder 3, 4
65
632461-2
1
Support Complete (Old)
66
634166-0
1
Field (MJ)
634246-2
1
Field (MCA)
67
*
2
Screw
68
415157-8
1
Fan Guide
69
911253-5
4
P.H. Screw M5x30
70
421447-9
2
Rubber (B)
71
263002-9
1
Rubber Pin 4
72
256221-4
1
Pin 3
73
233024-3
1
Compression Spring 4
74
415160-9
1
Lock Button
75
651920-7
1
Switch
76
256221-4
1
Pin 3
77
415158-6
1
Switch Lever
78
421446-1
4
Rubber (A)
79
*
1
Handle (L)
80
*
5
Screw
81
631149-1
1
Triac
82
415156-0
1
Controller Case
83
421448-7
1
Rubber Band
84
654020-2
2
Garter Spring
85
421452-6
1
Rubber Plate
86
265995-6
2
Tapping Screw 4x18
87
678063-9
1
Strain Relief
88
682503-2
1
Cord Guard 8-90
89
664013-1
1
Cord With Plug 2P-18-2.5
90
654501-6
2
Solderless Connector P-1.25
91
931102-0
5
Hex Nut M4
92
423234-2
1
Packing
93
423233-4
1
Seal Plate
Accessories
A01
- - - -
1
Recipro Saw Blade (See Catalogue for Details)
A02
783202-0
1
Hex Wrench 4
A03
191686-A
1
Makita Safety Glasses
A04
G-00001
1
Makita Safety Gloves
A05
A00188-3
2
Snap Lock (L)
A06
824412-1
1
Plastic Carrying Case (With A05)
Item
Part
No.
No.
No.
Used
Description
Item
Part
No.
No.
No.
U s e d Description
*
SEE SERVICE CHANGES
