E-20
Connecting Personal Computers and Video Equipment
Connections with the AUDIO Jack
* Make the connection to the projector’s AUDIO jack using the supplied audio cable. When the audio jack of the equipment that
is to be connected is of the RCA phono type, make connection via the supplied audio conversion cable.
* The built-in speaker of the projector provides monaural audio. To enjoy convincing audio reproduction, please connect the
audio output of the video equipment to your audio system.
* The built-in speaker outputs the audio of the equipment connected to the AUDIO jack.
R
L
AUDIO OUT
White
Red
Audio conversion cable
(Supplied item)
Audio cable (Supplied item)
Audio cable (Supplied item)
