Names of the Main Unit Parts
RGB S VIDEO VIDEO AUDIO MOUSE
STANDBY
STATUS
STANDBY
AUTO
SOURCE
PC CONTROL
ST ANDBY
STATUS
ST ANDBY
AUTO
SOURCE RGB
S VIDEO
VIDEO
AUDIO
MOUSE
PC C
ON TRO
L
STANDBY indicator [E-21, 58]
STATUS indicator [E-21, 58]
AUTO button [E-26]
STANDBY button [E-21]
SOURCE button [E-26]
Built-in Security Slot
This security slot supports the MicroSaver Security System manufactured by
Kensington Microware Inc.
Ventilation slots
Speaker
Built-in security slot
(See description below.)
AC IN connector [E-21]
Remote control sensor [E-13]
RGB connector [E-16, 19]
S-VIDEO connector [E-18]
VIDEO connector [E-18]
AUDIO connector [E-20]
MOUSE connector [E-32]
PC CONTROL connector
(D-Sub 9-pin) [E-33]
