K00044 STACKING KIT G-1200 TO G-1200
Installation Instructions
Parts List:
Item
Description Quantity Part Number
1. Lower Ice Chute Weldment (one with insulation) 2 6639114
2. Upper Ice Chute Weldment 2 6639014
3. Front Chute Support 1 6608614
4. Top Front Mounting Bracket 1 6638614
5. Bottom Front Mounting Bracket 1 6638714
6. Bottom Rear Mounting Bracket (Angle  ) 2 6213314
7. Top Rear Mounting Bracket (90  ∟) 2 6213214
8. Water Shield Weldment 1 6653414
9. Stabilizer Bracket 1 6639214
10. #10-32 x 1/2 Machine Screw 1 5027021
11. 1/4-20 x 5/8 Hex Brass Machine Screw 2 5031841
12. #10-24 x 5/8 Self-tapping Screw 12 5202053
13. #10-24 x 3/8 Self-tapping Screw 6 5202103
14. #10-32 Hex Nut 1 5429431
15. 1/4-20 Hex Nut 2 5429531
16. #8-32 Wing Nut 12 5489021
17. 1/4 Split Ring Lock Washer 2 5545111
18. #10 Split Ring Lock Washer 1 5573163
19. Installation Instructions 1 8003273
20. Locking Plate 1 6236814
21. Foam Tape 250” 9202393
22. Corner Brace 1 6604714
23. Curtain Stop 1 6267914
Installation Instructions:
1. The K044 stacking kit is used for stacking two G-1200 ice machines or a G-1200 on an E-1100 or G-1700 ice
machine. The bin must be leveled before proceeding to step 2.
2. INSTALLATION OF CORNER BRACE:
A. Remove foam tape, as shown on Illustration 1.
B. Remove seven screws on the top of the bin and locate corner brace, as shown in Illustration 1. Secure with seven
screws previously removed.
C. Use foam tape from kit around the perimeter of corner brace, as shown in Illustration 1.
3. INSTALLATION OF MACHINES:
A. See service manual for uncrating and inspection of both machines.
B. Remove top cover from lower machine.
C. Set machine carefully and squarely on bin.
D. Position water shield from kit, as shown in Illustration 2. Apply foam tape on the perimeter and across partition
panel, as shown in Illustration 2.
E. Set top machine carefully and squarely on bottom machine.
F. Remove front, back, and side panel on the evaporator end of both machines.
Manitowoc Ice, Inc.
2110 South 26 Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA 8003273
Telephone 920-682-0161, Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879 Page 1 of 2
Web Site -
www.manitowocice.com Rev. 05/16/01
Installation Instructions (continued):
