Makita JR180DZ - Manual (Page 4)

4 Model JR140DWA
4 Model JR140DZ
4 Model JR180DWB
4 Model JR180DZ
Item No. Description Type 1 Type 2 Type 3
18 Stop Ring E-3 961017-7 - - - - - See Change
on Tool-less
Blade Change
System(Service
Change # 4)
20 Pin 4 268044-8 - - - - -
22 Shoe Supporter 344813-2 344925-1
Serial # JR140DWA/JR140DZ ~ 3400A 3401A ~
Serial # JR180DWA/JR180DZ ~ 22912A 22913A ~
Above parts are completely interchangeable as a set.
2. Modification of Shoe Supporter.
3. Change on Torx Socket Head Bolt M5X10 and Addition of Spring Washer 5.
Item No. Description Type 1 Type 2 Type 3
6 Torx Socket Head Bolt M5X10 266247-8 266272-9
See Change
on Tool-less
Blade Change
System (Service
Change #4)
78 Flat Washer 5 941102-2 - - - - -
79 Spring Washer 5 942101-7 - - - - -
83 Spring Washer 5 - - - - - 267758-6
Serial # JR140DWA/JR140DZ ~ 4312A 4313A ~
Serial # JR180DWB/JR180DZ ~ 24880A 24881A ~
Above parts are completely interchangeable as a set.
