Page 2
2 Model JR140DWA
2 Model JR140DZ
2 Model JR180DWB
2 Model JR180DZ
1
911228-4
4
P.H. Screw M5X18
2
*
1
Gear Housing Cover Com.
3
216002-8
1
Steel Ball 4.8
*
4
256454-1
1
Pin 5.5-6
*
5
310138-6
1
Clamp (Old 310088-5)
*
310138-6X
1
Clamping System Repair Kit (Includes
Items 3 - 10 & 83)
6
*
1
Torx Socket Head Bolt M5X10
7
162215-8
1
Push Button
*
8
323916-5
1
Push Pin
*
9
233018-8
1
Compression Spring 3
*
10
233247-3
1
Compression Spring 16
*
11
257226-7
1
Ring 13
*
12
443070-0
2
Plate 12X16
13
214169-6
2
Plane Bearing 14
14
168328-3
1
Slider
*
15
341462-6
2
Plate
16
911225-0
4
P.H. Screw M5X16
17
344801-9
1
Shoe Plate/Shoe
*
18
961017-7
1
Stop Ring E-3 (Old)
*
19
252103-8
1
Hex Lock Nut M5-8
*
20
268044-8
1
Pin 4 (Old)
*
21
266241-0
1
Hex Socket Head Bolt M5X50
*
22
*
1
Shoe Supporter
23
421693-4
1
Insulation Cover
24
911114-9
1
P. H. Screw M4X10
25
257558-2
1
Sleeve 9
26
344732-2
1
Inner Plate
27
344733-0
1
Lock Plate
28
152904-3
1
Lever 60 Com. (With Item 30)
(Old 272240-2)
29
921442-4
1
Hex Bolt M8X25
30
931102-0
1
Hex Nut M4
31
266220-8
1
Torx Socket Head Bolt M6X15
32
212001-8
1
Needle Bearing 708
33
153267-0
1
Gear Com.
34
285696-0
1
Bearing Retainer A
35
211061-7
1
Ball Bearing 6000LLB
36
257146-5
1
Ring 10
37
210057-5
1
Ball Bearing 6900LLB
38
323887-6
1
Gear Shaft
39
251969-3
2
Hex Socket Head Bolt M5X12
40
344795-8
1
Plate C
41
443107-3
1
Felt 8X24
42
317229-4
1
Gear Housing
43
266012-5
4
Tapping Screw 5X35
44
911601-8
3
P.H. Screw M5X8
45
961016-9
1
Stop Ring E-10
46
211131-2
1
Ball Bearing 6001DDW
47
961016-9
1
Stop Ring E-10
48
285697-8
1
Bearing Retainer B
49
911516-9
2
P.H. Screw M4X12
50
416960-0
1
Fan Guide
51
519052-5
1
Armature Assy (JR140DWA)
(Includes Items 55, 56 & 70)
519051-7
1
Armature Assy (JR180DWB)
(Includes Items 55, 56 & 70)
52
416959-5
1
Baffle Plate
53
266209-6
2
Tapping Screw 4X60
54
632828-4
1
Yoke Unit
55
681652-2
1
Insulation Washer
56
210017-7
1
Ball Bearing 607DDW
57
851730-4
1
Name Plate JR140D
851734-6
1
Name Plate JR180D
58
416957-9
1
Motor Housing
59
819720-3
2
Makita Label
60
191970-5
2
Carbon Brush CB-429 (2pcs/Set)
61
643949-7
1
Brush Holder R
62
643941-3
2
Holder Cap
63
643950-2
1
Brush Holder L
64
183140-0
1
Handle Set (JR140DWA)
183141-8
1
Handle Set (JR181DWB)
65
231469-9
1
Compression Spring 4
66
416958-7
1
Lock-Off Button
67
911006-2
1
P.H. Screw M3X8
68
416976-5
1
Stopper
69
265995-6
6
Tapping Screw 4X18
70
241869-5
1
Fan 55
71
231469-9
1
Compression Spring 4
72
689090-2
1
Heat Sink
73
654195-7
1
Spring Terminal (Plus)
74
687085-9
1
Holder
75
651980-9
1
Switch (JR140DWA)
651979-4
1
Switch (JR180DWB)
76
263002-9
2
Rubber Pin 4
77
654196-5
1
Spring Terminal (Minus)
78
941102-2
1
Flat Washer 5 (Old)
79
942101-7
1
Spring Washer 5 (Old)
80
655000-B
1
Plug for Cigarette Lighter
81
942101-7
1
Spring Washer 5
*
Item
Part
No.
No.
No.
Used
Description
Item
Part
No.
No.
No.
Used
Description
