2 . R e m o v e t h e c o v e r f r o m y o u r A p p l e I I .
Pull up on the rear edge of the cover until the fasteners at the rear
corners pop apart. Do this only firmly enough to separate the fas-
teners, then stop. Do not pull up any further.
3 . S l i d e t h e c o v e r b a c k w a r d .
Slide the cover away from the keyboard towards the rear of your
Apple II. The interior of your Apple II should now be exposed.
Removing A Chip
Before you can install RAMCard, you must remove one of the RAM
chips inside your Apple II. Later, you will insert the plug on the RAM-
Card connector cable into the space where the chip is now.
1 . L o o k i n t o y o u r A p p l e I I .
Familiarize yourself with the inside.
power supply cover edge connector slot
memory chip to be removed RAM chips located
in this square
The Interior of an Apple II
10
