LOCATIONS OF CONTROLS
back panel
AERIAL TERMINAL
MTV68
MTV34/ MTV51
VIDEO OUT
VIDEO IN
AUDIO IN
AUDIO OUT
AUDIO OUT
AUDIO IN
VIDEO IN
VIDEO OUT
MTV51/ MTV 34
MTV68
FRONT AUDIO INPUT
FRONT VIDEO INPUT
TV/AV SELECT
MENU SELECT
VOLUME DOWN
VOLUME UP
PROGRAM UP
PROGRAM DOWN
MAIN POWER ON/OFF SWITCH
INFRA-RED RECEIVING WINDOW
STAND-BY MODE INDICATOR
front panel
