3.2 - Advanced Menu
You can select any of the items in the left frame of the screen, such as Super I/O
Configuration, to go to the sub menu for that item. You can display an Advanced
BIOS Setup option by highlighting it using the keys. All Advanced BIOS
Setup options are described in this section. The Advanced BIOS Setup screen is
shown below. The sub menus are described on the following pages.
BIOS Setup Utility
Main Advanced PCI/PnP Boot Security Chipset Exit
Advanced Settings
WARING: Setting wrong values in below sections may
cause system to malfunction.
CPU Configuration
IDE Configuration
Super IO Configuration
USB Configuration
ACPI Configuration
AHCI Configuration
Hardware Health Configuration
IPMI 2.0 Configuration
Intel VT-d Configuration
PCI Express Configuration
Remote Access Configuration
Trusted Computing
Onboard Devices Configuration
Options for CPU
←
→ Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
Feature Option Description
Advanced Settings
CPU Configuration Menu Item Options for CPU
IDE Configuration Menu Item Configure the IDE device(s)
Super IO Configuration Menu Item
Configures Super IO Chipset
Win627DHG
USB Configuration Menu Item Configure the USB support
ACPI Configuration Menu Item
Section for Advanced ACPI
Configuration
AHCI Configuration Menu Item
Section for Advanced AHCI
Configuration
Hardware Health
Configuration
Menu Item
Configure/monitor the
Hardware Health
IPMI 2.0 Configuration Menu Item
IPMI configuration including
server monitoring and event log
