McCulloch MCT3362VA User Manual
Page 6
26-8
9SSKKBB-05-18
SCREW
1
190
27
6SDABB04-16
SCREW
4
190
28
9017-336203
ENGINE COVER (REAR)
1
190
29
9134-334501
SCREW
1
190
30
9017-336210
FILTER COVER
1
190
31
9183-334501
AIR FILTER
1
190
32
9SGEB-05-52
SCREW
2
190
33
9228-336216
AIR BOX / CHOKE ASS'Y INCL 33-1, 33-2, 33-3, 33-4,
1
190
33-5, 33-6, 33-7, 33-8, 33-9, 33-10, 33-11, 33-12
33-1
6SLABB03-10
SCREW
1
190
33-2
9263-336201
CHOKE PLATE
1
190
33-3
9263-336203
CHOKE DRIVER
1
190
33-4
9263-336202
CHOKE LEVEL
1
190
33-5
6SLABB03-10
SCREW
1
190
33-6
9017-336207
FILTER SUPPORT
1
190
33-7
9188-336202
FILTER SHAFT
1
190
33-8
9188-336201
FILTER SPRING BRACKET
1
190
33-9
9024-336204
FILTER SPRING
1
190
33-10
9014-336204
FILTER AIR COVER GASKET
1
190
33-11
9123-336201
FILTER AIR COVER
1
190
33-12
6SLABB03-10
SCREW
2
190
34
9287-336201
CARBURETOR
1
190
35
9014-GP0104
CARBURETOR GASKET
1
190
36
9SKKB-05-19
SCREW
4
190
37
9129-336201
FILTER PIPE
1
190
38
9024-336206
FILTER PIPE CLAMP
2
190
39
9012-334501
GROMMET
1
190
40
9072-336202
INSULATOR
1
190
41
9014-334506
SEAL
1
190
42
9228-MD0107
PAWLS ASY
1
190
43
9157-332101
INSULATOR GASKET
1
190
44
9228-340103
CRANKCASE ASY
1
190
45
9DB-620101
BEARING
2
190
46
9014-334502
GASKET (CRANKCASE SIDE)
1
190
47
9CB-32
C RING
1
190
48
9157-334501
SEAL
1
190
49
9169-336201
FLYWHEEL
1
190
50
9228-334506
FUEL TANK ASY INCL 50-1, 50-2, 50-3, 50-4, 50-5,
1
190
50-6, 50-7, 50-8, 50-9, 50-10
50A
AO9066-GP0201-US888
FILTER ASS'Y INCL 50-2, 50-3, 50-4
1
190
