Engine ass'y, Parts list – McCulloch MCT3362VA User Manual
Page 5
Engine Ass'y
9238-336203
6/23/2009
No.
Parts No.
Description
Q
P Code
1
9295-310502
SPARK PLUG
1
190
2
9SGEB-05-10
SCREW
2
190
3
9211-336202
PLATE(SPARK SIDE)
1
190
4
9012-330301
GROMMET
1
190
5
9SRCB-05-22
SCREW
4
190
6
9SXMBJ05-50
SCREW
2
190
7A
AO9228-336221-US888
MUFFLER KIT INCL 6, 7, 8
1
190
7
9228-336221
MUFFLER ASY
1
190
8
9211-336201
MUFFLER PLATE
1
190
9
9SGEB-04-10
SCREW
4
190
10
9017-336201
CYLINDER COVER
1
190
11
9014-336202
GASKET
2
190
12
9292-336201F
CYLINDER
1
190
13
9017-336206
CYLINDER COVER
1
190
14
9014-336201
GASKET
1
190
15
9189-GP0101
PISTON RING
2
190
16A
AO9228-336231-US888
PISTON ASS'Y INCL 15, 16, 17, 18, 19, 20
1
190
16
9290-336201
PISTON
1
190
PARTS LIST
16
9290-336201
PISTON
1
190
17
9131-334501
C CLIP
2
190
18
9067-334501
AXIS COVER
2
190
19
9115-336201
PISTON PIN
1
190
20
9NR-KV9129.8
NEEDLE BEARING
1
190
21
6221-830301
KEY
1
190
22
9228-334502
CRANK/ROD ASY
1
190
23
9288-334701
IGNITION COIL
1
190
24
9SGEB-05-20
SCREW
2
190
25
9SGKB-05-12.5
SCREW
5
190
26
9228-336211
STARTER HOUSING ASY INCL 26-1, 26-2 ,26-3,
1
190
26-4, 26-5, 26-6, 26-7, 26-8
26-1
9017-336208
STARTER HOUSING
1
190
26-2
6068-320002
HANDLE
1
190
26-3
9199-GP0101
BUSHING
1
190
26-4
9024-330503
SPRING
1
190
26-5
9194-330501
PULLEY
1
190
26-6
9299-330501
ROPE
1
190
26-7
9014-MD0106
WASHER
1
190
PARTS LIST
