9. Connecting headphones
Headphones can be connected to the TV by way of the connecting socket underneath the fascia cover at the front. The socket will only
accept headphones with a 3.5 mm (Carat/Stratos 6.3 mm) jack plug.
We recommend the use of headphones with an impedance of at least 32 Ohms. Headphones of a lower impedance (down to approx.8
Ohms) will impair the sound quality.
The headphones volume can be stored as a standard value. The headphones and the TV speakers can be used together.
In the event of 2-channel sound transmissions it is possible to listen to either channel 1 or 2 on the headphones, irrespective of the chan-
nel set for the TV speakers.
Press this key on the remote
control....
The screen displays
Explanation
1. Switch off the TV speakers
and adjust the headphones
volume
2. Store the headphones volu-
me as a standard value
Sound mode selection for
headphones
AV
OK
P
+
+
-
AV
--/-
-
P
1
2
3
4
5
6
7
8
9
0
A
B
TV
?
MENU
48
42
23
-
+
-
+
00
-
+
36
Audio standard values
Volume
Treble
Balance
Bass
Volume headphones
6 9 6 + 0 4 B - G B
?
MENU
return
Help
TV
store ?
OK
It is advisable to switch off the TV speakers with the
key when adjusting the volume for the headphones.
Press the yellow key to display the bar for the head-
phones volume.
Adjust the volume with the
keys.
+
-
The standard value for the headphones volume can
only be stored by way of the TV menu.
All standard values can be stored in the „Audio stan-
dard values“ submenu.
The volume has already been adjusted (see step 1).
It is now only necessary to press the
key to store
the headphones volume.
OK
With two-channel sound transmissions it is possible to
select either channel 1 or channel 2.
If headphones are connected, it is possible to listen,
for example, to the English sound track on the spea-
kers (channel 1) and to the other language on the
headphones (channel 2).
This setting can also be called with the sound mute
active by pressing the yellow key. The desired channel
can then be selected with the
keys.
+
-
9. Headphones
Volume
+
-
MENU
OK
3. Return to TV picture
TV
TV picture
6 9 6 + B Y G B
change
+
-
OK
Volume headphones
65
B 1 5 - G B
change
+
-
OK
Sound-mode headphones
Mono / stereo / Chann.1 / Chann.2
yellow
yellow
yellow
yellow
