Dash Disassembly 95-3302
9
Chevrolet Malibu 2008-2010
1. Unsnap and remove shifter trim.
Note: Start around shifter and be sure
to pull down before back because this
panel slides up under the radio/climate
panels. (Figure A)
2. Remove (2) 8 mm screws from bottom
of radio/climate panel.
3. Unsnap and remove the climate/radio
panel and upper vent trim panel
together (they can be separated after
removal). (Figure B, C)
4. Remove (6) 8 mm screws from radio
and climate controls.
Continue to kit assembly
(Figure A)
(Figure C)
(Figure B)
