Dash Disassembly 95-3302
8
Chevrolet Malibu 2004-2007
5. Unclip and remove side panel from
passenger side of dash with door open
and remove (2) 7 mm screws from
behind panel. (Figure E)
6. Remove (2) 7 mm screws from bottom
of glove box then open box and squeeze
sides together to open further and
remove the remaining (4) 7 mm screws.
Unclip the black vent cover under the
glove box then unclip and remove entire
glove box assembly. (Figure F)
7. Unclip and remove trim panel
surrounding radio and climate controls.
(Figure G)
8. Remove (4) 7 mm screws securing the
radio and (2) 7 mm screws securing the
climate control. Unplug and remove the
radio. (Figure H)
Continue to kit assembly
(Figure F)
(Figure H)
(Figure G)
(Figure E)
