Kit Assembly 95-3302
17
Stacked ISO mount radio provision
1. Slide the stacked ISO DIN units into the
trim plate bracket assembly and secure
the units to the kit using the screws
supplied with the head units. (Figure A)
2. Slide the stacked ISO DIN unit into the
trim plate bracket assembly and secure
the unit to the kit using the screws
supplied with the head unit. (Figure B)
3. Aura, Cobalt, G5, HHR, Sky and
Vue only: Cut and remove top mounting
tabs on each side of the radio housing.
(Figure C)
4. Locate the factory wiring harness in the
dash. Metra recommends using the
proper mating adapter from Metra or
AXXESS. Re-connect the negative
battery terminal and test the unit for
proper operation.
5. Reassemble dash in reverse order
of disassembly.
(Figure A)
(Figure C)
(Figure B)
Cut the two top holes off
