Model H8235 3-Piece Framing/Brad/Palm Nailer Kit -19 -
Brad Nailer Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 PH8235101 SPECIAL BOLT 134 PH8235134 PIN
102 PH8235102 EXHAUST PORT 135 PH8235135 BRACKET
103 PH8235103 COMPRESSION SPRING 136 PH8235136 COMPRESSION SPRING
104 PB42M HEX BOLT M5-.8 X 20 137 PH8235137 SAFETY NOSE
105 PLW01M LOCK WASHER 5MM 138 PH8235138 DRIVER GUIDE
106 PH8235106 CYLINDER CAP 139 PH8235139 SPACER
107 PORP014 O-RING 13.8 X 2.4 P14 140 PSB15M CAP SCREW M5-.8 X 20
108 PH8235108 SEALING RING 141 PSB23M CAP SCREW M4-.7 X 12
109 PH8235109 COMPRESSION SPRING 142 PSB17M CAP SCREW M4-.7 X 10
110 PH8235110 PLUNGER 143 PH8235143 DRIVER GUIDE COVER
111 PORS031-5 O-RING 31.0 X 2.0 S31.5 144 PH8235144 NAIL GUIDE LINER
112 PORP025 O-RING 24.7 X 3.5 P25 145 PH8235145 MAGAZINE SEAT
113 PH8235113 CYLINDER CAP GASKET 146 PSS35M SET SCREW M4-.7 X 16
114 PH8235114 CYINDER SLEEVE 147 PH8235147 MAGAZINE CAP
115 PORP029-5 O-RING 29.2 X 3.5 P29.5 148 PH8235148 BRACKET
116 PORS042 O-RING 2.0 X 41.5 S42 149 PSB41M CAP SCREW M4-.7 X 14
117 PH8235117 CYLINDER 150 PH8235150 PUSHER
118 PORP022 O-RING 21.8 X 2.4 P22 151 PH8235151 PUSHER SHAFT
119 PH8235119 PISTON W/DRIVER 152 PH8235152 COMPRESSION SPRING
120 PH8235120 BUMPER 153 PLN01M LOCK NUT M4-.7
121 PH8235121 NAILER BODY 154 PH8235154 PIN
122 PH8235122 RUBBER WASHER 155 PH8235155 LATCH TORSION SPRING
123 PH8235123 SEAL 156 PH8235156 LATCH
124 PH8235124 INNER VALVE SEAT 157 PSB18M CAP SCREW M4-.7 X 8
125 PH8235125 TRIGGER VALVE 158 PH8235158 LATCH BRACKET
126 PORP011-2 O-RING 11 X 2.4 P11.2 159 PSB16M CAP SCREW M4-.7 X 16
127 PH8235127 TRIGGER VALVE GUIDE 160 PH8235160 RUBBER HAND GRIP
128 PORP011-2 O-RING 11 X 2.4 P11.2 161 PORP036 O-RING 35.7 X 3.5 P36
129 PH8235129 COMPRESSION SPRING 162 PH8235162 CAP
130 PH8235130 STEP PIN 163 PH8235163 AIR VALVE 1/4 NPT
131 PH8235131 TRIGGER 164 PH8235164 PISTON REPAIR KIT
132 PEC01M E-CLIP 3MM 165 PH8235165 O-RING REPAIR KIT
133 PH8235133 SAFETY PLATE
