Gold's Gym XR15 User Manual
Page 13
Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover
of the user’s manual for information about ordering replacement parts.
Key No.
Qty.
Description
Key No. Qty. Description
1
1
Bench Frame
2
1
Crossbar
3
2
Base
4
1
Front Leg
5
1
Curl Post
6
1
Leg Lever
7
2
Support Upright
8
2
Upright
9
2
Upright Plate
10
2
Backrest Frame
11
1
Adjustment Bracket
12
1
Curl Pad
13
1
Seat
14
1
Backrest
15
1
Weight Tube
16
1
Adapter Tube
17
1
Front Leg Foot
18
4
Base Foot
19
2
Upright Joint Plate
20
4
Upright Support Plate
21
2
Front Leg Joint Plate
22
3
Pad Tube
23
6
Foam Pad
24
6
19mm Round Inner Cap
25
1
25mm Round Angled Cap
26
3
45mm Square Inner Cap
27
1
50mm Square Inner Cap
28
4
25mm Square Inner Cap
29
1
Spacer
30
2
Adapter Bushing
31
1
Curl Knob
32
2
Weight Rest
33
1
M8 x 58mm Bolt
34
6
M8 Washer
35
5
M8 Nylon Locknut
36
1
M4 x 16mm Screw
37
26
M10 Nylon Locknut
38
1
Backrest Pin
39
1
M10 x 156mm Bolt
40
18
M10 x 95mm Bolt
41
5
M10 x 68mm Bolt
42
1
Weight Clip
43
4
M10 x 45mm Bolt
44
4
M6 x 16mm Screw
45
5
M6 Washer
46
4
M6 x 38mm Bolt
47
3
25mm Round Inner Cap
48
4
M8 x 50mm Bolt
49
6
M10 Washer
50
1
M6 x 63mm Screw
51
10
M4 x 16mm Flat Head Screw
52
2
38mm x 76mm Inner Cap
#
1
User’s Manual
#
1
Exercise Guide
PART LIST—Model No. GGBE14821
R0603A
REMOVE THIS PART IDENTIFICATION CHART AND PART LIST/
EXPLODED DRAWING. SAVE THIS PART IDENTIFICATION CHART
AND PART LIST/EXPLODED DRAWING FOR FUTURE REFERENCE.
