Recline only works in modes where child restraint is attached to the base.
17.0
USING
RECLINE
FAILURE TO PROPERLY recline the infant restraint on
the vehicle seat increases the risk of serious injury or
death.
1. Pull up on recline button on front of
child restraint
A
.
2. Bubble in level indicator C must be
fully between the two lines D . E is
not level.
3. Vehicle must be on level ground and
child in child restraint when checking
level indicator.
NOTE: Level indicator is for
rear-facing use only.
FORWARD-FACING REAR-FACING
1. Pull up on recline button on front of
child restraint
B .
2. Adjust recline to desired level
indicated on label
F
on side of
base F .
If using seat with child 40-65lbs,
always use recline position 1.
