Grizzly H5571 User Manual
Page 13
H5571 34˚ Framing Nailer Kit
-12
-
1
PSB115M
BTN HD CAP SCR M6-1 X 16
2
PH5571002
EXHAUST COVER
4
PH5571004
RUBBER WASHER 10MM
5
PSB06M
CAP SCREW M6-1 X 25
6
PH5571006
CAP
7
PW09M
FLAT WASHER 7MM
8
PH5571008
SPACER
9
PH5571009
PISTON STOPPER
10
PH5571010
SPRING
11
PH5571011
O RING
12
PH5571012
PISTON HEAD VALVE
12-1 PH5571012-1 SPACER
13
PH5571013
O RING
14
PH5571014
SEAL
15-1 PH5571015-1 O RING
15-2 PH5571015-2 O RING
16A PH5571016A PISTON ASSEMBLY
19
PH5571019
CYLINDER RING
20
PH5571020
O RING
21
PH5571021
CYLINDER
21-1 PH5571021-1 O RING
22
PH5571022
BUMPER UPPER
23
PH5571023
GASKET
24
PH5571024
BODY
25
PH5571025
BUMPER BOTTOM
26
PH5571026
O RING
27
PH5571027
NOSE
28
PSB31M
CAP SCREW M8-1.25 X 25
29
PH5571029
PIN
30
PH5571030
RUBBER RING
31
PSB116M
BTN HD CAP SCR M5-.8 X 14
32
PH5571032
GUIDE SAFETY LEVER
34A PH5571034A SAFETY LEVER ASM.
35
PLN02M
LOCK NUT M5-.8
36
PH5571036
SPRING
37
PH5571037
SAFETY LEVER
38
PLN03M
LOCK NUT M6-1
39
PH5571039
DEPTH ADJUSTING KNOB
40
PH5571040
RUBBER PAD
41
PH5571041
O RING
42
PH5571042
O RING
43
PH5571043
VALVE
44
PH5571044
O RING
45
PH5571045
O RING
46
PH5571046
O RING
47
PH5571047
VALVE PLUNGER
48
PH5571048
O RING
49
PH5571049
SPRING
50
PH5571050
PLUNGER
51
PH5571051
O RING
52
PH5571052
PLUNGER CAP
53A PH5571053A TRIGGER ASSEMBLY
56
PH5571056
PUSHER
57
PH5571057
STOPPER
58
PH5571058
SPRING
59
PH5571059
GASKET
60
PH5571060
SET PIN
61
PSB26M
CAP SCREW M6-1 X 12
62
PH5571062
SPIRAL SPRING
63
PH5571063
ROLLER
64
PH5571064
BALL PIN
65
PH5571065
MAGAZINE
66
PH5571066
NAIL GUIDE LINER
67
PSB26M
CAP SCREW M6-1 X 12
68
PH5571068
DEBRIS SHIELD
70
PH5571070
STOPPER BLOCK
72
PSB117M
BTN HD CAP SCR M5-.8 X 8
73
PH5571073
BRACKET
74
PLN04M
LOCK NUT M8-1.25
78
PSB116M
BTN HD CAP SCR M5-.8 X 14
80
PH5571080
3/8" NPT CONNECTOR
82
PW01M
FLAT WASHER 8MM
83
PH5571083
GASKET WASHER
84
PH5571084
PIN
85
PH5571085
SPACER
87
PH5571087
PISTON GUIDE WASHER
88
PLW04M
LOCK WASHER 8MM
89
PW05M
FLAT WASHER 4MM
90
PSB18M
CAP SCREW M4-.7 X 8
91
PH5571091
SPRING
92
PH5571092
SET BALL
95
PH5571095
IDLE ROLLER
96
PSB118M
BTN HD CAP SCR M5-.8 X 20
97
PH5571097
MAGAZINE BLOCK
100 PH5571100
ROLLER
REF
PART #
DESCRIPTION
REF
PART #
DESCRIPTION
