-20- G7945/46 Radial Drill Press
Design Type ......................................................................................................Floor Model
Overall Dimensions:
Table ........................................................................................................12 3 ⁄
16
'' Round
Overall Height........................................................................................................64 1 ⁄
2
''
Overall Width ............................................................................................................14''
Overall Depth............................................................................................................32''
Column Diameter ................................................2.790" (Vertical), 2.356" (Horizontal)
Quill Diameter ................................................................................................... 0.575''
Shipping Weight ................................................................................................150 lbs.
Box Size ..................................................................................55" L x 20
1 ⁄
2
" W x 10" H
Footprint ........................................................................................................18" x 11"
Construction:
Table ..................................................................................Precision Ground Cast Iron
Column....................................................................................Cylindrical Ground Steel
Base & Head ..................................................................................................Cast Iron
Capacities :
Spindle Travel..........................................................................................................3 1 ⁄
4
''
Max. Distance, Spindle to Base ..............................................................................51''
Max. Distance, Spindle to Table............................................................................30
1 ⁄
2
''
Spindle Nose ..........................................................................................................B-16
Swing ....................................................................................................................33
1 ⁄
2
''
Chuck Size ...................................................................................... 5 ⁄
8
'' (16mm), keyed
Speeds ..............................................................................................5, Belt Controlled
Range of Speeds ..................................................550, 880, 1520, 2490, 3470 R.P.M.
Head Radial Movement ........................................................................................12
1 ⁄
2
''
Head Radial Pivot ..........45° Clockwise, 90° Counter-Clockwise, Positive Stop @ 90°
Drilling Capacity............................................................................
1 ⁄
2
'' Diameter in Steel
Motor:
Type ............................................................................TEFC Capacitor Start Induction
Horsepower ........................................................................................................
1 ⁄
2
H.P.
Phase / Cycle ..............................................................................Single Phase ⁄ 60 Hz
Voltage ..................................................................................................................110V
Amps............................................................................................................................5
R.P.M. ....................................................................................................................1720
Power Transfer ..........................................................................................V-Belt Drive
Bearings ..............................................................Shielded & Lubricated Ball Bearings
Switch ..................................................................Toggle ON/OFF w/ Safety Lock Tab
Features:
Table ..360° Swivel Around Table Center, 270° Swivel Around Pivot 6'' from Column,
360° Swivel Around Support Column, Tilt -90° to + 90°, Lock Levers
Vertical Table Movement ............................Crank Handle Operated Rack and Pinion
Slots..................................................................................................6 radial slots, 5 ⁄
8
'' x 3 1 ⁄
4
'',
Depth Gauge ..................................................On Feed Handle Hub, Inch Increments
Specifications, while deemed accurate, are not guaranteed.
Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
GRIZZLY MODEL G7946 FLOOR RADIAL DRILL PRESS
MACHINE DATA
SHEET
