Grizzly H7951 User Manual
Page 25
h7949/h7950/h7951 nailer
-22
-
h7951 parts list
page 1 of 2
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
1
PFH55M
FLAT HD CAP SCR M6-1 X 20
39
PH7951039
FEED PAWL
2
PH7949002
FRONT BRACKET
40
PH7951040
STEPPED PIN
3
PH7949003
EXHAUST COVER
41
PH7949041
O-RING
4
PH7949004
EXHAUST FILTER
42
PH7951042
FEED PISTON
5
PH7949005
EXHAUST FILTER PLATE
43
PH7949043
O-RING
6
PSB38M
CAP SCREW M5-.8 X 25
44
PH7949044
SPRING
7
PH7949007
CAP
45
PRP22M
ROLL PIN 4 X 32
8
PH7949008
SPRING
46
PH7949046
FEED PISTON STOP
9
PH7949009
WASHER
47
PH7949047
SPRING COLLAR
10
PH7949010
O-RING
48
PH7949048
O-RING
11
PH7949011
PISTON HEAD VALVE
49
PH7951049
STEPPED PIN
12
PH7949012
O-RING
50
PH7951050
RATCHET
13
PH7949013
SEAL
51
PH7949051
SPRING
14
PH7949014
PLAIN WASHER
52
PH7951052
DOOR
15
PH7949015
PISTON STOPPER
53
PH7951053
NAIL SUPPORT
16
PH7949016
O-RING
54
PH7949054
SPRING
17
PH7949017
PISTON
55
PH7949055
SET SHAFT
18
PH7951018
DRIVER
56
PH7951056
SLIDE ROD
19
PH7951019
CYLINDER
57
PH7951057
MAGAZINE
20
PH7949020
O-RING
58
PSBS09M
BUTTON HD CAP SCR M5-.8 X 12
21
PH7949021
CYLINDER RING
59
PSB53M
CAP SCREW M5-.8 X 18
22
PH7949022
COLLAR
60
PLN02M
LOCK NUT M5-.8
23
PH7949023
O-RING
61
PH7951061
MAGAZINE COVER
24
PH7949024
GASKET
62
PRP42M
ROLL PIN 3 X 20
25
PH7949025
BODY
63
PH7951063
ADJUSTING BLOCK
26
PH7949026
PAD
64
PH7951064
SAFETY LEVER
27
PH7949027
O-RING
65
PH7951065
ROLL PIN 3 X 8
28
PH7949028
BOTTOM BUMPER
66
PW03M
FLAT WASHER 6MM
29
PH7949029
O-RING
67
PSBS06M
BUTTON HD CAP SCR M5-.8 X 12
30
PH7951030
NOSE
68
PH7951068
NOSE COVER
31
PSB02M
CAP SCREW M6-1 X 20
72
PRP97M
ROLL PIN 3 X 30
32
PH7951032
STEPPED PIN
73
PH7949073
TRIGGER VALVE CAP
33
PH7949033
RETAIN RUBBER
74
PH7949074
O-RING
34
PH7949034
RETAIN RUBBER
75
PH7949075
PLUNGER
35
PH7951035
STEPPED PIN
76
PH7949076
SPRING
36
PH7951036
SPRING
77
PH7949077
O-RING
37
PH7951037
DOOR LOCK
78
PH7949078
O-RING
38
PH7949038
PROTECTOR
