Replacement Parts
7-7
7
ID No. Part Number Description
144 061551-002 CABLE ASSY, MOTOR MAIN STEPPER
147 059102-002 BRACKET, MOTOR MOUNT
148 061554-004 PLATE, MOTOR
149 061584-002 SUBPLATE, LINER TAKEUP
151, 154 505359-001 SCREW, W/CONE WASH, 8-32X1
153 061588-002 GEAR, LINER REVERSE
156 062603-001 PLATE, HUB ADJUST
157 061583-002 SUBPLATE, TTR
158 061574S-001 CLUTCH, ASSY, SELF STRIP LINER TAKE-UP, 3600 SPARE
159 506040-007 WASHER, FLAT SST 446 X .56
161 061589-001 SHAFT, LINER REVERSE
162, 163 501462-003 O-RING, 2.800ID X .210THK
164 506040-006 WASHER, FLAT SST .327 X .500 X .080
166 061565-002 CLAMP, LINER HUB
not shown 061605-001 CORE, RIBBON, 3600, CDBD, 6.7 IN.
not shown 062197S-003 FIRMWARE, 3600, VER 1.1, SPARE
3600 Manuals
Part No. Description
062732-001 3600 Bar Code Label Printer User’s Manual
062733-001 3600 Bar Code Label Printer Getting Started Guide
