Replacement Parts
7-5
7
ID No. Part Number Description
61 585525-001
585525-002 XFMR, 3600, 47-63HZ, 100V/120V
XFMR, 3600, 47-63HZ, 200V/240V
62 041776 JUMPER AY, .25 TERM. LUGS, 4-IN
63 060246-001 FILTER ASSY, LINE AC
64 506103 WASHER, LOCK, EXT. STAR, NO.
65 501273-001 CIRCUIT BREAKER, SWITCH, 2 AMP
65 501273-002 CIRCUIT BREAKER, SWITCH, 1 AMP
67 506111 WASH. LOCK. SPLIT, NO. 4
68 060544-001 GASKET, ESD, RS232 CONNECT
69 507659-001 SCREW, JACK, 4-40X .312
71 586229 BATTERY, LITHIUM 3.6V, 1.75AH
72, 145 525034-001 SCREW, THD ROLL W/CONE, 8-
74, 93, 106,
108, 132 506013 WASHER, SST, .255ID X .407OD
75 506827-001 SPRING, COMP. 360 OD .44F
77 059122-001 LEVER, PRINTHEAD ADJUSTMENT
78 507717 FASTENER, COTTER PIN 25
79 061561-001 SPRING, TORSION, PRINTHEAD RETURN
80 061560-001 SHAFT, TTR RIBBON
81, 100, 136 501409 RETAINING RING .250 DIA BASIC
82 059039-011 HANDLE, PRINTHEAD PRESSURE
84 063225-001 PLATE, UPPER MODULE, OUTBD
85 061576S-002 CAM ASSEMBLY, HEAD PRESSURE
88 061568-002 ROLLER, LINER DRIVE
89 061542-003 ROLLER, PLATEN
90 061543-002 ROLLER, DRIVE
91 061558-002 BAR, STRIP SUPPORT
92, 109, 134 501401 RTN RING .250 DIA 8610/2
94 061541-001 BAR, TEAR
96, 131 501394-001 MOUNT, WIRE ROUTING, ADH B
97 059423-002 MOUNT, MARK SENSOR
