H8203 Professional Drill Sharpening Machine
-25-
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
1
PH8203001
BASE PLATE
35
PSBS24M
BUTTON HD CAP SCR M4-.7 X 10
2
PH8203002
ANGLE BRACKET
36
PSB03M
CAP SCREW M5-.8 X 8
3
PH8203003
SWIVEL SLEEVE
37
PSB03M
CAP SCREW M5-.8 X 8
4
PH8203004
SPECIAL CAP SCREW
38
PSB14M
CAP SCREW M8-1.25 X 20
5
PH8203005
CALIBRATING DEVICE BASE
39
PH8203039
SWITCH
6
PH8203006
CALIBRATING PLATE
40
PH8203040
COLLET 1/8"
7
PH8203007
SPECIAL SET SCREW
41
PH8203041
COLLET 5/32"
8
PH8203008
COLLET HOLDER
42
PH8203042
COLLET 3/16"
9
PH8203009
LOCK RING
43
PH8203043
COLLET 1/4"
10
PH8203010
COMPRESSION SPRING
44
PH8203044
COLLET 9/32"
11
PH8203011
FLANGE
45
PH8203045
COLLET 5/16"
12
PH8203012
CLEANING BRUSH
46
PH8203046
COLLET 3/8"
13
PH8203013
MOTOR BRACKET
47
PH8203047
COLLET 25/64"
14
PH8203014
ADJUSTING BLOCK
48
PH8203048
COLLET 7/16"
15
PH8203015
FAN
49
PH8203049
COLLET 15/32"
16
PH8203016
GRINDING WHEEL CBN 170
50
PH8203050
COLLET 1/2"
17
PH8203017
MOTOR 110V, 1/6 HP
51
PH8203051
POWER CORD
18
PH8203018
BALLAST
52
PH8203052
STRAIN RELIEF
19
PH8203019
FOOT
53
PSS51M
SET SCREW M4-.7 X 8
20
PH8203020
CALIBRATING DEVICE COVER
54
PH8203054
FUSE 5A
21
PH8203021
GRINDING WHEEL COVER
55
PH8203055
LIMIT SWITCH
22
PH8203022
MOTOR COVER
100
PH8203100
READ MANUAL LABEL 2-3/4" X 1-1/2"
24
PH8203024
HANDLE
101
PH8203101
DISCONNECT POWER LABEL 2-3/4" X 1-1/2"
25
PH8203025
CALIBRATING DIAL
102
PH8203102
KEEP COVER CLOSED LABEL 2-3/4" X 1-1/2"
26
PSB41M
CAP SCREW M4-.7 X 14
103
PH8203103
MACHINE ID LABEL
27
PSB06M
CAP SCREW M6-1 X 25
104
PH8203104
ANGLE SCALE LABEL
28
PSB20M
CAP SCREW M5-.8 X 14
105
PH8203105
CALIBRATING DIAL LABEL
29
PSB41M
CAP SCREW M4-.7 X 14
106
PH8203106
DRILL DIAMETER LABEL
30
PSB33M
CAP SCREW M5-.8 X 12
107
PH8203107
ELECTRICITY LABEL
31
PSB20M
CAP SCREW M5-.8 X 14
108
PH8203108
GRIZZLY GREEN TOUCH UP PAINT
32
PSB20M
CAP SCREW M5-.8 X 14
109
PH8203109
BLACK TOUCH UP PAINT
33
PSB50M
CAP SCREW M5-.8 X 10
110
PH8203MAN H8203 MANUAL 11/7
34
PSS31M
SET SCREW M5-.8 X 8
Parts List
Safety labels warn about machine hazards and ways to prevent injury. The owner of this machine
MUST maintain the original location and readability of the labels on the machine. If any label is
removed or becomes unreadable, REPLACE that label before using the machine again. Contact
Grizzly at (800) 523-4777 or www.grizzly.com to order new labels.
