Ga-8i945plge-rh motherboard layout, Ga-8i945plge-rh – GIGABYTE GA-8I945PLGE-RH User Manual
Page 6
- 6 -
GA-8I945PLGE-RH Motherboard Layout
GA-8I945PLGE-RH
CD_IN
CODEC
RTL
8111B
CI
F_AUDIO
IT8712
ATX_12V
CPU_FAN
LGA775
ATX
RF_ID
BAT
ICH7
PCI2
PCI3
SYS_FAN
SATAII2
FDD
F_PANEL
CLR_CMOS
PCI1
F_USB1
F_USB2
IDE1
SPDIF_I
DDRII1
DDRII2
Intel 945PL
PCIE_16
PCIE_1
PCIE_2
SATAII0
PWR_LED
KB_MS
COAXIAL
LPT
USB
VGA_COM
USB
LAN
AUDIO1
AUDIO2
OPTICAL
SATAII3
SATAII1
BIOS
