-22-
Model g4181/g7873 1-hp power Feeder
if you damage one or more wheels, you can easily
replace the wheels.
tools Needed Qty
• hex Wrench 5mm ....................................... 1
to replace a wheel:
1. disConnECt thE poWEr FEEdEr
FroM poWEr!
Wheel Replacement
Figure 16. Wheel replacement.
2. Using a 5mm hex wrench, remove the two
wheel retaining cap screws ( Figure 16).
always disconnect power
to the machine before
performing maintenance.
Failure to do this may
result in serious person-
al injury.
3. swap the old wheel with the new.
4. reinstall the two cap screws, and tighten in
an alternating pattern until the wheel is sec-
cure
.
Cap
screw
