Installation Instructions
27
REPLACE DOOR ASSEMBLY
Replace a door screw in the center of the side
opposite the hinge. Then put the male end of the
latch into place and fasten with two door screws.
3
Fasten the hinge back on at the top and bottom
with the hinge mounting screws.
REPLACE DOOR ASSEMBLY (CONT.)
Move the mounting screw to the upper screw hole
position on the hinge so that the door can be set
on the cabinet during final installation.
3
Replace all door screws that were removed.
Remove the female end of the latch from the front
panel of the dryer, rotate 180° and replace on
the opposite side.
