Installation Instructions
REVERSE THE DOOR SWING (cont.)
Reverse the hinges:
• Using a flat putty knife, remove the screw hole plugs
opposite the door hinges, top and bottom. Set aside.
• Remove the two screws holding top hinge.
• Turn the hinge upside down, with the hinge pin
pointing up. Reinstall the hinge on the opposite side
at the bottom of the door.
• Remove the bottom hinge. Turn the hinge upside
down and install on the opposite side at the top.
• Push screw hole plug buttons (supplied) into the
original screw holes.
• Remove the top hinge pin.
• Place plastic hinge sleeve on the bottom hinge and
position the door onto the pin.
• Place plastic hinge sleeve in the top hinge hole on
the door. Align the door on the bottom hinge and
replace top hinge pin.
• Reinstall handle with original screws.
Hinge Pin
Hinge Sleeve/
Door Stop
Hinge
Plugs
Hex Head Hinge Screw
Plugs
Hinge Sleeve/
Door Stop
Hex Head
Hinge Screw
Hinge Pin Hinge
Top Hinge
Bottom Hinge
REVERSE THE DOOR SWING (cont.)
To reverse the door catch:
• Remove the plastic screws
from the opposite side
of the door.
• Remove the metal screws
from the magnetic door
catch and reinstall on the
opposite side of the door.
• Install the plastic screw
into place on the opposite
side of the door.
Reverse
Door Catch
Position
Top Hinge
Bottom Hinge
