15
4. Align the laser beam with the line on the workpiece.
5. The laser beam can be aligned to be parallel with the
blade by adjusting the laser line. Loosen the laser
adjustment knob and move the laser beam until it is in
line with the blade. Tighten the laser adjustment knob.
6. To start the saw push the on/off switch to the ‘ON’
position.
7. To begin the cut guide the wood into the moving
saw blade.
8. Use only enough pressure to keep the saw cutting. Do
not force the cutting, allow the blade and the saw to do
the work.
9. When cutting on a bevel angle ensure that the rip fence
is located on the right hand side of the blade.
10. When cutting rod, use a jig or fixture to prevent the
workpiece from turning.
11. When cutting boards vertically, use a suitable push block
to feed the workpiece into the saw.
12. Once finished turn off the tool by pushing the red button
on the switch cover and unplug the tool from the power
point to prevent unauthorised use.
Power cord maintenance
If the supply cord needs replacing, the task must be carried
out by the manufacturer, the manufacturer’s agent, or an
authorised service centre in order to avoid a safety hazard.
Cleaning
1. Keep the tool’s air vents unclogged and clean at all times.
2. Remove dust and dirt regularly. Cleaning is best done
with a soft brush or a rag.
3. Re-lubricate all moving parts at regular intervals.
4. Never use caustic agents to clean plastic parts.
CAUTION. Do not use cleaning agents to clean the
plastic parts of the tool. A mild detergent on a damp
cloth is recommended.
General inspection
Regularly check that all the fixing screws are tight. They
may vibrate loose over time.
