Goodman Mfg GPC1424H41AB - Manual (Page 9)

Compressor and Top Panel Assembly
Ref.
No: Part
No:
Description:
Ref.
No: Part
No:
Description:
Image 1:
INSULATED ASSY, TOP PANEL 0274G00037 11
FAN BLADE (M4, M5) 0150G00004 21
FAN BLADE (M1, M2) 0150G00005 21
FAN BLADE, TYPE 3 (M3) B1086765 21
COND MOTOR 1/4 HP, 1 SP, 6 PL (M4, M5) 0131M00007PS 31
COND MOTOR 1/4 HP, 1 SP, 8 PL (M3) 0131M00061S 31
COND MOTOR, 1/6 HP, 1 SP, 8 PL (M1, M2) 0131M00009P 31
FAN GRILLE 0152G00002S 41
SMALL SCREW (QTY 6) M0221817 61
ACORN NUT 5/16 HEX BLACK (QTY 4) 0163M00006P 71
PVC CONDUIT 8.25" 17788000083F NS
Image 2:
COMPRESSOR 20000, 208/230/60/1 (M1) ZP20K5EPFV130 12
COMPRESSOR 24000, 208/230/60/1 (M2) ZP24K5EPFV130 12
COMPRESSOR 31100, 208/230/60/1 (M3) ZP31K5EPFV830 12
COMPRESSOR 34500, 208/230/60/1 (M4) ZP34K5EPFV130 12
COMPRESSOR 39000, 208/230/60/1 (M5) ZP39K5EPFV830 12
COMPRESSOR GROMMET (M1, M2) B1339530 22
COMPRESSOR GROMMET (M3, M4, M5) B1339533 22
TF SHOULDER SCREW (QTY 4) M0221641 32
COMPRESSOR SCROLL HARNESS 0159G00004 NS
Expanded Model Nomenclature
M1 - GPC1424H41AB
M2 - GPC1430H41AB
M3 - GPC1436H41AB
M4 - GPC1442H41AB
M5 - GPC1448H41AB
9 RP-622A www.goodmanmfg.com www.amana-hac.com
